Indoor Battery Cage Poultry Farming Saving Feed Unique Cross - Opening Door Design

Henan Muke Livestock Breeding Machinary Co .,Ltd

Indoor Battery Cage Poultry Farming Saving Feed Unique Cross - Opening Door Design

  • 1
  • 2

Brand Name : Hongsheng

Model Number : HS-04

Certification : ISO 9001, SONCAP

Place of Origin : Henan Province, China

MOQ : 20 sets

Price : USD 50-120

Payment Terms : Western Union, T/T, D/P, D/A, L/C

Supply Ability : 10000 sets per month

Delivery Time : 20 work days

Packaging Details : A or H types of Chicken Layer Cage will be packed as standard or as request.

Application : layer chicken cage

Size : 1800*600*430mm/1200*625*480mm

Material : galvanized

Capacity : 128 birds, 192 birds, 240 birds

Warranty : 15-20 years

Weight : 80 kgs, 72 kgs

System : automatic

Accessories : feeder, water pipe, nipples, etc

Contact Now

Supply complete set automatic H type layer chicken cage machine

Chicken cage category
1. Raising egg-laying chicken, named layer cage, after pullet growing up to 12 weeks to 16 weeks, it is near adult and starts laying the egg, transfers to egg laying chicken cage.
2. Rearing baby egg-laying chicken, named chick cage or baby chicken cage, from 1 day old to 12 weeks, the feeding trough and drinking line will adjust the height as baby chick cage.
3. Rearing broiler from 1 day old to 45 days after broilers ready for market, named broiler cage, broilers will live in one cage of whole life.
Check my product list to learn different kinds and size of the chicken cage.

Chicken cage specification

Item 3 tiers 2 doors 3 tiers 4 doors 4 tiers 2 doors 4 tiers 4 doors 5 tiers 4 doors
Capacity(Set) 96 birds 144 birds 128 birds 192 birds 240 birds
Capacity(Cell) 8 birds 6 birds 8 birds 6 birds 6 birds

Cage Size

(L*W*H)

1.2m*1.3m*1.5m 1.8*1.2m*1.5m 1.2m*1.3m*2.2m 1.8m*1.2m*2.2m 1.8m*1.2m*2.75m
Materials Low carbon steel wire,, Q235 steel wire

Surface

Treatment

Cold Galvanization

Hot Dip Galvanization

Bottom

wire mesh angle

Lifespan

Cold Galvanization (7-10 years)

Hot Dip Galvanization(15-20 years

Package

Full container loading:cage and cage frame are no package,

some fittings are in plastic bags and carton box

Less container loading: packed in wooden box and pallet

Chicken cage feature

1.The surface of the cage can be selected from cold galvanizing and hot dip galvanizing processes;
2, chicken cage structure is simple, easy to operate, sturdy and durable;
3, chicken cage net and bottom net encryption, effectively prevent chickens from licking the anus phenomenon, reducing the egg breaking rate and laying chicken fatigue syndrome;
4. The bolded structure of the front mesh wire is firmer, the structure is reasonable, and the energy consumption is low;
5. Unique cross-opening door design, the cage door space is larger, and the position of chicken feeding can be changed arbitrarily, which effectively solves the crowding of chickens when eating, ensuring that the birds eat more evenly;
6. Saving feed, it will also reduce the stress response of laying hens and the chance of chicken injury, save water, and have low egg breaking rate;
7. Good ventilation and lighting, which is conducive to the growth of chickens, high stocking density, small floor space, high degree of intensification and good economic benefits; suitable for all types of farm houses (open, semi-open and closed)

Automatic system

Automatic Feeding Equipment

Automatic numerical control feeding machine, give feed balance, operate steadily, low noise, high efficiency, easy to operate, save man power and long life time.

Automatic Drinking Equipment

The front-end drinking system can use filter, intelligent water meter, import medicine adding device(import dosing pump) and water regulator that can choose by yourself according to your demand. It also design the water cup or V type water trough below the nipples, tail end has the water level display tube, convenient to water observation.

Automatic Egg Collection Equipment

Using import electrical machine, running stable, low noise, the rate of breakdown is low. Corner and drive side use import sealing rubber strip, the rate of egg broken less than five over ten thousand.

Automatic manure removal equipment

Import PP material manure belt, strong and durable, use our company own anti-meandering technology, control the manure belt meandering effectively.

Services

1) Pre-sales service:

a. according to your budget, our professional design team can recommend you one suitable model and design the reasonable chicken shed layout for you;

b. our modern sample exhibition hall and workshop welcome you to visit at any time.

2) After-sales service:

a. to give the installation and breeding guidance for all customers;

b. to give phone follow-ups for the equipment application;

c. to provide maintenance service for the equipment within the quality guarantee period.
